Tektronix OpenChoice Alternatives in 2026 (Free & Cross-Vendor)

Tektronix OpenChoice is a free set of desktop utilities for getting data and screen images off Tektronix oscilloscopes. It handles connection over USB or LAN, screen capture into documents, waveform transfer into Excel, and a Talker Listener console for sending raw commands.

It does that job adequately and it costs nothing. It is also single-vendor, barely developed, and stops precisely where validation work starts. This post covers what it does, the specific point at which everyone outgrows it, and the five alternatives.

What OpenChoice actually covers

For an engineer who needs a scope screenshot in a report, this is genuinely the fastest route. Connect, capture, paste. Done.

Where everyone outgrows it

The wall is always the same, and it arrives the first time the measurement needs a condition to be set before it is taken.

"Capture the ripple on the 1.8 V rail at 500 mA load, at 25 and 85 degrees, at three input voltages."

That is nine captures, and OpenChoice can help with none of the setup. It cannot command the power supply. It cannot command the electronic load. It cannot step the conditions, wait for settling, check a limit, or write a verdict. It captures whatever is on the screen when you press the button.

So the workflow becomes: a human sets the supply, sets the load, waits, presses capture in OpenChoice, renames the file, and repeats nine times. Then correlates them in Excel.

That is the point to leave.

The alternatives

1. tm_devices (Tektronix Python)

Free and open source, and Tektronix's own supported Python package. This is the intended successor for automation and it is considerably better than OpenChoice's scripting.

from tm_devices import DeviceManager

with DeviceManager() as dm:
    scope = dm.add_scope("192.168.1.50")
    scope.commands.horizontal.scale.write(1e-3)
    scope.commands.ch[1].scale.write(0.5)
    scope.commands.trigger.a.edge.source.write("CH1")
    scope.commands.acquire.state.write("RUN")
    vpp = scope.commands.measurement.meas[1].results.currentacq.mean.query()

Good for: all-Tektronix benches. Typed command access, device discovery, and proper error handling.

Gives up: other vendors. It is a Tektronix library and does not pretend otherwise.

Verdict: if your bench is Tektronix, use this instead of OpenChoice, today. It is strictly better and equally free.

2. TestFlow

Covers the whole sequence rather than the capture. You add the scope, supply, and load by model and VISA address, describe the measurement in plain English, and the agent generates the automation, runs the nine-point matrix, and produces the report with pass and fail per point.

Good for: the exact scenario that breaks OpenChoice, which is a measurement with conditions.

Gives up: the instant screenshot-into-Word workflow, which OpenChoice does well and which remains a reasonable reason to keep it installed.

Verdict: the answer when the scope is one instrument in a test, not the test itself.

3. Python with PyVISA

Free and vendor-neutral. The general answer.

import pyvisa

rm = pyvisa.ResourceManager()
scope = rm.open_resource("TCPIP0::192.168.1.50::inst0::INSTR")
psu = rm.open_resource("TCPIP0::192.168.1.42::inst0::INSTR")

for vin in (3.0, 3.3, 3.6):
    psu.write(f"VOLT {vin}")
    psu.write("OUTP ON")
    scope.write("ACQUIRE:STATE RUN")
    scope.write("MEASUREMENT:IMMED:TYPE PK2PK")
    scope.write("MEASUREMENT:IMMED:SOURCE CH1")
    ripple = float(scope.query("MEASUREMENT:IMMED:VALUE?"))
    print(f"VIN {vin} V -> ripple {ripple*1000:.1f} mVpp "
          f"{'PASS' if ripple < 0.05 else 'FAIL'}")
psu.write("OUTP OFF")

Good for: exactly the case OpenChoice cannot do. The supply and the scope in one loop, with a verdict.

Gives up: requires Python. That is the whole cost.

Verdict: the default. See the PyVISA tutorial and the Tektronix Python guide.

4. Keysight BenchVue

No-code, application-based, and it does drive some third-party instruments. Mentioned because it is the closest thing to "OpenChoice but better and cross-vendor", though it leans heavily toward Keysight hardware.

Good for: engineers who want a UI rather than code, on a Keysight-leaning bench.

Gives up: money, and full Tektronix support. See Keysight BenchVue alternatives.

Verdict: not really an OpenChoice replacement for a Tektronix bench. Listed for completeness.

5. PicoScope software

Free with Pico hardware, and genuinely good software. Worth knowing about because for some measurements a USB scope with good software beats a benchtop scope with poor software.

Good for: teams buying new, where the software quality can influence the hardware choice.

Gives up: it needs Pico hardware. It will not help with the Tektronix scope you already own.

Verdict: relevant at purchase time, not at migration time.

Comparison table

A sensible setup

There is no reason to uninstall OpenChoice. It costs nothing and it is the fastest path to a screenshot.

The practical arrangement most labs land on:

• •Keep OpenChoice for ad-hoc screenshots into reports and for the Talker Listener console when debugging a SCPI string. It is good at both.
• •Use `tm_devices` or PyVISA for anything repeated more than twice.
• •Use a platform layer when the test spans several instruments and needs a report.

The mistake is treating OpenChoice as the automation story. It was never that, and Tektronix's own investment in tm_devices says so.

Migrating a screenshot habit into something repeatable

Most OpenChoice usage is one workflow: capture the screen, paste into a report. Replacing that with code is straightforward and worth doing, because the captured image then carries the conditions that produced it.

import pyvisa

rm = pyvisa.ResourceManager()
scope = rm.open_resource("TCPIP0::192.168.1.50::inst0::INSTR")
scope.timeout = 20000

scope.write("SAVE:IMAGE:FILEFORMAT PNG")
scope.write("HARDCOPY START")
raw = scope.read_raw()

name = f"ripple_vin3v3_load500ma_25c.png"
with open(name, "wb") as f:
    f.write(raw)
print(f"saved {name} ({len(raw)} bytes)")

The gain is not the automation, it is the filename. A screenshot called tek0003.png is worthless in six months. One called ripple_vin3v3_load500ma_25c.png is evidence, and generating it from the loop that set those conditions means it can never be mislabelled.

Extend the same idea to the report: capture the image, record the numeric measurements alongside it, and write both into the run record. That is the difference between a folder of screenshots and a validation result.

When staying on OpenChoice is fine

Not everything needs automating, and it is worth saying where the effort does not pay back.

• •One-off debugging. You are chasing a problem, you need a picture, you will never do it again. OpenChoice is faster than writing anything.
• •Teaching and demonstration. Showing someone a waveform.
• •Sanity-checking a fixture before starting a scripted run.
• •Fewer than about five repetitions. Below that threshold, scripting costs more than it saves.

The rule of thumb: automate at the third repetition, not the first. Automating a measurement you will take twice is a hobby, not engineering. The reason OpenChoice frustrates people is not that it is a bad tool, it is that it gets used well past the point where the third repetition arrived.

Getting waveform data out properly

The other thing people use OpenChoice for is pulling the waveform record into Excel. Doing it in code is not much harder and gives you the scaling factors, which the OpenChoice export can lose.

scope.write("DATA:SOURCE CH1")
scope.write("DATA:ENC RIBINARY")
scope.write("DATA:WIDTH 2")
scope.write("DATA:START 1")
scope.write("DATA:STOP 100000")

ymult = float(scope.query("WFMOUTPRE:YMULT?"))
yoff  = float(scope.query("WFMOUTPRE:YOFF?"))
yzero = float(scope.query("WFMOUTPRE:YZERO?"))
xincr = float(scope.query("WFMOUTPRE:XINCR?"))

raw = scope.query_binary_values("CURVE?", datatype="h", container=list)
volts = [(point - yoff) * ymult + yzero for point in raw]
times = [i * xincr for i in range(len(volts))]

The four scaling queries are the part that matters. Raw curve data is in digitiser levels, not volts, and applying YMULT, YOFF, and YZERO is what converts it. Skipping that step is the most common reason exported waveforms look like nonsense.

The three habits worth replacing first

OpenChoice-era workflows tend to share the same three manual steps. Each has a direct automated equivalent that takes under an hour to build, and replacing them in this order gives the fastest return.

The third one is where the actual time goes, and it is also where transcription errors live. A characterisation run with twenty operating points is twenty chances to type a number into the wrong cell.

Pulling a screenshot without the USB stick

The single highest-return replacement, because it removes a walk to the bench.

import datetime, pathlib

scope.write("HARDCopy:PORT ETHERnet")
scope.write("HARDCopy:FORMat PNG")
scope.write("HARDCopy:LAYout LANdscape")
scope.write("HARDCopy:PALEtte INKSaver")     # white background, prints properly

png = scope.query_binary_values("HARDCopy STARt", datatype="B", container=bytes)

stamp = datetime.datetime.now().strftime("%Y%m%d-%H%M%S")
out = pathlib.Path("captures") / f"scope-{stamp}.png"
out.parent.mkdir(exist_ok=True)
out.write_bytes(png)
print(f"saved {out}")

INKSaver is worth setting: the default palette is the scope's dark screen, which looks poor in a report and uses a lot of toner. The timestamped filename is the other half of the point, since the naming problem is what makes a folder of screenshots unusable six months later.

Older TDS-series scopes use HARDCopy:PORT GPIb and a slightly different format list, so check HARDCopy? on your model before assuming the block above transfers.

Capturing the numbers instead of the picture

The upgrade from the screenshot habit. Same instrument, same session, but the output is a row of values you can plot, diff, and compare against limits.

import csv

MEASUREMENTS = [("PK2PK", "CH1"), ("MEAN", "CH1"), ("FREQuency", "CH1"), ("RISe", "CH1")]

def read_measurements(scope):
    row = {}
    for kind, source in MEASUREMENTS:
        scope.write(f"MEASUrement:IMMed:TYPe {kind}")
        scope.write(f"MEASUrement:IMMed:SOUrce {source}")
        row[f"{source}_{kind.lower()}"] = float(scope.query("MEASUrement:IMMed:VALue?"))
    return row

with open("sweep.csv", "w", newline="") as fh:
    writer = None
    for v_in in (10.8, 12.0, 13.2):
        psu.write(f":SOUR:VOLT {v_in}")
        time.sleep(0.5)
        scope.write("ACQuire:STOPAfter SEQuence")
        scope.write("ACQuire:STATE ON")
        scope.query("*OPC?")                 # block until the acquisition completes
        row = {"vin": v_in, **read_measurements(scope)}
        if writer is None:
            writer = csv.DictWriter(fh, fieldnames=list(row))
            writer.writeheader()
        writer.writerow(row)

The *OPC? query is the important line. Without it the script reads measurements from whatever the scope had on screen before the new acquisition finished, which produces plausible numbers that are silently one operating point stale.

Common mistakes

• •Keeping the screenshot as the record. An image cannot be re-measured or plotted against anything. Capture the numbers, and generate the image from them.
• •Untimestamped filenames. scope1.png through scope40.png is not a dataset.
• •Installing the vendor suite on a machine that also runs NI drivers. VISA implementations can collide. Pick one primary VISA and be deliberate about it, see instrument control with VISA and SCPI.
• •Assuming OpenChoice commands map to current models. The MSO and MDO series moved on. Check against the current programmer manual.
• •Automating the screenshot and stopping there. It is the easy win, not the valuable one. The sweep loop is where the hours are.
• •Leaving the scope on auto-trigger during automated capture. You will capture whatever was on screen, not the event. Set the trigger explicitly and use single-sequence acquisition.
