newshipped August 2026

Introducing TestFlow Agentsdescribe the test in plain English,the agent drives your instruments

TestFlow Agents read the bench you actually have, write the automation and the test plan from your request, and run it on the real hardware. Editable test automation, not code snippets.

Download TestFlow book a demo →

speaks to the instruments already on your bench

what shipped

Three things had to be true at once

An agent that writes test automation is only useful if it knows the bench it is writing for, and only trustworthy if you can read and run what it wrote. This release is all three.

the agent

Plain English in, real automation out

Ask for a VI sweep from 0 to 3.3 V in 100 mV steps and the agent writes the instrument automation and the structured test plan behind it. Both are editable before anything runs, and both are yours to keep.

the bench

Grounded in the instruments you own

The agent writes against the bench it can see: your models, your VISA addresses, your channels. Any vendor, over USB, LAN, GPIB, or serial. It is not generating a snippet for a datasheet it was trained on.

the run

It executes, then it reports

Values stream in against their limits step by step on real hardware, and the run ends in a report rather than a spreadsheet someone assembles on Friday. The next revision reruns the same workflow.

the loop

The request, the workflow it wrote, and the run

The chat, the workflow the agent generated, the ATOMS script behind it, and the executor stepping through it against the limits. Every panel here is the product’s own.

AgentTestFlow · bench

Load transient test: sweep 5-20 V, capture CH1

I’ll sweep the USB-PD levels inside a loop, step the dynamic load, and capture the scope response at each level.

Generated workflow5 nodes

Loop4 iterations · ${v_load_sweep}
Power SupplyKeithley 2450
OscilloscopeTektronix MDO
Delay1000 ms
Dynamic LoadChroma 6200P

Run it on the bench

Running on the connected bench. Four iterations, asserting overshoot under 200 mV.

iteration 3 of 4

PASS4 of 4 iterationsworst overshoot151 mVripple pk-pk38 mVtotal run6.4 s

Load transient test: sweep 5-20 V, capture CH1Describe a test, or ask for a change

Workflow6 steps3 instrumentswritten in 4s

No workflow yet

Start

Loop × 4${v_load_sweep}

Power SupplyKeithley · 2450

1.Set VoltageV=${v_load_sweep}
2.Turn On:OUTP ON

OscilloscopeTektronix · MDO

1.Set Timebase1 ms
2.Measure AmplitudeCH1

3Delay 1000 ms

Dynamic LoadChroma · 6200P

1.Set Current2.5 A step
2.Output On:INPut ON

End

Script/load_transient.atomsATOMS

// no script yet

#START_SCRIPT
Loop_start(1): 4 (N1)
Variable: v_load_sweep
Range: (5,20)
#NODE1 (Power Supply, 2450, Keithley)
INST:: SMU_2450
CMD: :SOUR:FUNC VOLTage
CMD: :SOUR:VOLT ${v_load_sweep}
CMD: :OUTP ON
#NODE2 (Oscilloscope, MDO, Tektronix)
INST:: MDO_01
CMD: HORizontal:SCAle 0.001
CMD: MEASUrement:IMMed:TYPe AMPLitude
QRY: MEASUrement:IMMed:VALue?
ASSERT: overshoot < 200mV
#NODE3 (Delay)
Delay: 1000,ms
#NODE4 (Dynamic Load, 6200P, Chroma)
INST:: LOAD_6200P
CMD: :CURR 2.5
CMD: :INPut ON
Loop_end(1)
#END_SCRIPT

PSU Load Transient0.0s0.4s0.8s1.2s1.6s2.0s2.4s2.8s3.2s3.6s4.0s4.4s4.8s5.2s5.6s6.0s6.4sRunning

Startsession opened
Power SupplySOUR:VOLT 5.0 · OUTP ON
Oscilloscope1 ms timebase · CH1
Delay1000 ms
Dynamic Load2.5 A step

Execution log

12:41:02VISA open USB0::0x05E6::0x2450 … OK
12:41:02VISA open USB0::0x0699::0x0522 … OK
12:41:02VISA open USB0::0x1698::0x0837 … OK
12:41:03Loop 1/4: v_load_sweep = 5.0 V
12:41:03:SOUR:VOLT 5.0 · :OUTP ON
12:41:04HORizontal:SCAle 0.001
12:41:04CH1 5.02 V · overshoot 138 mV
12:41:06CH1 15.01 V · overshoot 147 mV
12:41:07CH1 20.03 V · overshoot 151 mV
12:41:08overshoot < 200 mV, PASS (4/4)

Live capture · Tektronix MDOAcquiringCaptured

CH1 5 V/divCH2 100 mV/div AC1 ms/div · trig CH1 ↗ 2.5 V

Vpp 15.01 Vovershoot 147 mVripple 37 mVCH1 · 15 V level

level	overshoot	undershoot	ripple	settling
5 V	138 mV	121 mV	34 mV	1.6 ms
9 V	142 mV	126 mV	36 mV	1.7 ms
15 V	147 mV	133 mV	37 mV	1.8 ms
20 V	151 mV	138 mV	38 mV	1.8 ms
worst	151 mV	138 mV	38 mV	1.8 ms
limit	< 200 mV	< 200 mV	< 50 mV	< 3 ms
margin	24%	31%	24%	40%

PSU Load Transient.pdf · written by the run

how it works

From the request to the report, in four steps

Connect your instruments

Pick the manufacturer and model, paste the VISA address. Any vendor, no NI hardware required, no drivers to write.

Tell the agent what to test

In plain English. Or ask it what to test for a power-management device and pick from what it proposes.

Read what it wrote

The workflow and the executable automation arrive in seconds, side by side. Nothing is hidden between what you described and what will drive the bench.

Run it in the lab

Click Run. TestFlow drives the real instruments, checks every reading against its limit, and hands back the results.

available now

Put the agent on your bench this week

Connect one instrument, ask for one test, and see what it writes. That is the whole evaluation.

Download TestFlow

Want it walked through on your own instruments? Book a demo, or read the instruments we support.
